iA 210 utilizes a high quality neodymium 1.4' horn throat compression tweeter with 75 mm (3') voice coil and two 10” high output ferrite mid-low driver with 65mm voice coil and humidity resistant paper cone, coupled with an optimized waveguide (10° vertical and 100° horizontal dispersion). iA 210 ensures extraordinary performance with penetration and smoothness.
Ultra compact and solid enclosure made from 15mm or 18mm high quality plywood and finished with durable polyurea paint for installation use.
iA 210 can be flown with bass speakers(iA 118B) and full range speaker (iA 208) together as main PA. The 3-point rigging system offers angle adjustment from 0 to 10° with 1° step.
The official EASE FOCUS 3 GLL data for iA 210 is available.
Driver Bit: The driver bit is the device that transfers impact and rotation to the crown bit for drilling. Download dynex network & wireless cards driver. The driver bit locks into two or four flats on the casing crown, and they act together as a standard drill bit; both the driver bit and the crown have tungsten carbide buttons. To put the system into program mode, lift the rubber cap on the GT-DA-L and press and release the program button using a long thin tool, such as a small screw driver. If using the GT-DM enter the programming mode and select Programming in the menu. The In-Use LED will blink for approximately 6-15 seconds, then remain lit solid. Driver1999GTInteractiveUSSLUS-00842GH Identifier-ark ark:/13960/t0wq1k90j Ocr ABBYY FineReader 8.0 Pages 33 Ppi 72 Year 1999. Plus-circle Add Review. Reviews There are no reviews yet. Be the first one to write a review. DOWNLOAD OPTIONS download 1 file.
Frequency Response | 100Hz--18kHz(±3dB) |
70Hz--20kHz(-10dB) | |
Sensitivity (@1w / 1m) | 102dB |
Nominal Impedance | 16Ω |
Power Rating (AES) | 700W |
LF Driver | 2x10' (65mm="" voice="" coil),=""> |
HF Driver | 1x3' (1.4'="" throat)="" neodymium="" compression="" driver="" (75mm="" voice=""> |
Nominal Coverage | 100°H x 10°V |
Maximum SPL | 130dB SPL, 136dB SPL Peak |
Dimensions (H x W x D) | 332 x 580 x 491 mm |
Weight | 35 kg |
Connection | 2 x Neutrik NL4MP;1+1- |
Case material | 15mm, 18mm multilayer plywood |
Finish | Black polyurea paint |
Grill | Black steel mesh + acoustic transparent cloth |
